Specifications

  • Size Range:
    3"-36"
  • Temperature Range:
    0°-250°F
  • Operating Pressure (CWP):
    3”-12” 250 PSI, 14"-36" 150PSI
  • Body Materials:
    Ductile Iron, ASTM A536 - GR 70-50-05
  • Seat Materials:
    Resilient Seated – Buna-N; Metal Seated – Bronze
  • Hinge Pin:
    Stainless Steel
  • Disc Materials:
    Ductile Iron, ASTM A536 - GR 70-50-05
  • Body Style:
    FLG
  • Design/Testing Standard:
    AWWA C508
  • Flange Drilling:
    ANSI B16.1 Class 125
  • Certifications:
    NSF 61, NSF 372
  • Accessories:
    L&W, L&S, Air Cushion, Oil Cushion, Limit Switch

Features & Benefits

  • Bronze or resilient seated
  • Working parts removable through top of valve for ease of maintenance
  • Stainless steel hinge pin
  • NSF/ANSI 61/372 Certified
  • Fusion bonded epoxy coated
  • ANSI B16 125# flange connection
  • Sizes 3”-12” 200 psi rated working pressure
  • Sizes 14”-36” 150 psi rated working pressure
  • Size 30” - 36” valves come standard with double lever arms
  • Full waterway flow through the valve equal to nominal diameter of the pipe
  • Horizontal or vertical (flow up) installation
  • Field adjustable to best adapt to operating conditions
  • Dual lever arms available for extreme rapid flow reversal applications
